AG514K1TB
- InterfacePCI-Express 5.0×4, NVMe 2.0
- Form FactorM.2 2280
- Total Capacity1000GB
- NAND3D TLC NAND Flash
- External DDR CacheLPDDR4 2GB
- Sequential Read speedUp to 13,600 MB/s
- Sequential Write speedUp to 10,200MB/s
- Dimension80 x 22 x 3.5 mm
- Mean time between failure (MTBF)1.6 million hours
- Max. Operating PowerRead : 11.5W; Write : 11.5W
- Power Consumption (Idle, PS3)< 144mW
- Power Consumption(PS4, L1.2)< 85mW
- Temperature (Operating)0°C to 70°C
- Temperature (Storage)-40°C to 85°C3. When the usage of an NVME SSD as indicated by the “Percentage Used” (SMART ID: 05) in SMART page of “GIGABYTE SSD toolbox” reaches 100 means out of warranty. (A new unused product will show the number of 0)
- Note• Test system configuration: configuration may vary by models, we will choose the latest platform for verification.
• Performance may vary based on SSD’s firmware version and system hardware & configuration. Sequential performance measurements based on CrystalDiskMark and IOmeter 1.1.0.
• Speeds based on internal testing. Actual performance may vary.
• 1GB = 1 billion bytes. Actual useable capacity may vary.
